Solid timber panels

European Walnut - Finger Jointed Panels & Worktops

European Walnut finger jointed panel
  • Special order item
  • 18mm-45mm (composites up to 100mm)
  • Maximum size 5300x1210mm
  • Typical pallet size = 10 sheets per item
  • Supplied raw or coated with various coatings such as clear lacquer or oil
  • B3 bonded for high moisture conditions

Overview

Winwood Products is a supplier of the following European Walnut finger jointed panels & worktops:

Specially ordered in minimum quantity of full pallets per item, these finger jointed panels & worktops are constructed from 40mm wide European Walnut strips of varying length (250mm-600mm). The the strips are end-jointed with a finger joint profile (which is stronger than the natural wood) to achieve the panel length, and these jointed strips bonded together to achieve the final panel size.

The European Walnut strips making up the panel core and faces are bonded together with B3 water resistant glue, and the faces calibrated to 80 grit before being protected with shrinkwrapping

The panels can be supplied as produced, or cut or machined to pattern. They can also be supplied prefinished with lacquer, oil, wax or special finishes as required.

Please click on the main European Walnut page for details of the wood

Information

Technical details (general)

  • Construction:
    • Full thickness European Walnut strips ranging in length 250mm-600mm, finger jointed for length before edge-gluing together to produce the panel
      These panels & worktops are produced using 40mm wide strips
  • Standard thickness:
    • 18mm, 19mm, 25mm, 26mm, 27mm, 40mm, 42mm, 45mm
  • Special sizes:
    • All panels made to order up to maximum 5300x1210mm
  • Standard Finish:
    • Calibrated with 80 grit
  • Packaging:
    • Faces protected with shrinkwrapping
  • Tolerances:
    • Length/width: up to 1m @ ±1mm, up to 2m @ ±2mm , 2m & above @ ±3mm
    • Thickness: +0.2mm, -0.5mm
    • (Others by arrangement)
  • Face grades:
    • A/B
    • Other grading by arrangement
  • Bonding Quality:
    • B3 - High moisture applications
  • Other features:
    • Other woods can be incorporated into the construction of the panel to achieve a decorative or contrasting effect
